PWM-6BX | Digital Bass Restoration Processor with ParaBASS Control
The Power Acoustik PWM-6BX is a digital bass processor designed to maximize subwoofer performance. With multiple inputs, ParaBASS low-frequency contouring, and wide parametric bass control, this processor restores and enhances bass for a fuller, more impactful sound.
Power Acoustik PWM-6BX - Bass Restoration Processor
Elevate your audio experience with the Power Acoustik PWM-6BX Bass Restoration Processor. Built for enthusiasts who want maximum bass impact, the PWM-6BX uses advanced digital processing to restore low frequencies often lost in today’s compressed music formats — giving your system the punch it deserves.
Equipped with multiple input options (AUX/Low/High), the PWM-6BX integrates seamlessly into a variety of systems. Its ParaBASS low-frequency contouring allows precise shaping of bass response, while the wide and sweep parametric bass control lets you target and boost the exact frequencies you want. Add in subwoofer level control and the Bass Maximizer effect, and you gain complete authority over how your low end sounds and feels.
With a powerful 20dB pre-amp gain and three preamp outputs (6 channels), the PWM-6BX ensures your amplifiers receive a strong, clean signal. Delivering up to 7V RMS / 12V peak output, this processor keeps distortion low with an impressive 0.01% THD, 110dB signal-to-noise ratio, and 20Hz–20kHz frequency response. Adjustable equalizer bands (50Hz, 200Hz, 1kHz, 5kHz, 20kHz) and subsonic filtering (35–80Hz) allow for extensive system tuning with ±18dB cut/boost flexibility.
Compact and efficient, the PWM-6BX features a high-headroom PWM switching power supply, drawing just 250mA of current. Measuring 7”W x 5.1”D x 1.2”H, it installs easily while delivering professional-grade sound processing. Unlock the hidden depth in your music and redefine your bass with the PWM-6BX.
Inputs:
Inputs: 3 (AUX/Low/High)
Input Impedance: 20kΩ/60Ω(High Input)
Outputs:
Preamp Outputs: 3 (6 channels)
Maximum Output Level: 7V RMS/12V Peak
Output Impedance: 150Ω
Performance:
Total Harmonic Distortion: 0.01%
Frequency Response: 20Hz-20kHz
Signal to Noise: 110dB
Equalizer Frequencies: 50Hz, 200Hz,
1KHz, 5KHz, 20KHz
Subsonic Frequencies: 35-80Hz
Equalization Cut/Boost: ±18dB
General:
Power Supply: High Headroom
PWM Switching
Current Draw: 250mA
Recommended Fuse Rating: 1A
Dimensions: 7”W x 5.1”D x 1.2”H
